SPC564L70L3BCOSY
RoHS
/
Package 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 2MB FLASH 100LQFP
PDF
/
Inventory: 8108
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 14mm
Length 14mm
Technical
External Data Bus Width 64
ROM (words) 524288
Address Bus Width 32
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 32x12b
Bit Size 32
Connectivity CANbus, LINbus, SCI, SPI, UART/USART
Program Memory Size 2MB 2M x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 40MHz
Peripherals DMA, LVD, POR, PWM, WDT
Core Processor e200z4d
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 3V~3.63V
RAM Size 192K x 8
Speed 120MHz
Number of I/O 57
Oscillator Type Internal
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.63V
Base Part Number SPC564L
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
ECCN Code 3A991.A.2
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series Automotive, AEC-Q100, SPC56xL
Packaging Tray
Operating Temperature -40°C~105°C TA
Physical
Surface Mount YES
Package / Case 100-LQFP
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 26 Weeks
