SPC560P44L5CEFBR
RoHS
RoHS compliant
RoHS compliantPackage 144-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 32-Bit SPC560P44x e200z0h RISC 384KB Flash 3.3V 144-Pin LQFP T/R
PDF
/
Inventory: 2636
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 23 Weeks
Physical
Mounting Type Surface Mount
Package / Case 144-LQFP
Surface Mount YES
Number of Pins 144
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Series SPC56
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 144
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 5V
Terminal Pitch 0.5mm
Frequency 64MHz
Base Part Number SPC560P
Pin Count 144
Operating Supply Voltage 3.3V
Interface CAN, LIN, SPI, UART, USART
Memory Size 384kB
Oscillator Type Internal
Number of I/O 80
Speed 60 MHz
RAM Size 36K x 8
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor e200z0h
Peripherals DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 384KB 384K x 8
Connectivity CANbus, LINbus, SPI, UART/USART
Bit Size 32
Data Converter A/D 26x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
Address Bus Width 32
EEPROM Size 64K x 8
On Chip Program ROM Width 8
Boundary Scan YES
Low Power Mode NO
Number of Programmable I/O 106
Format FIXED-POINT
Integrated Cache NO
Number of External Interrupts 32
Number of DMA Channels 16
Dimensions
Length 20mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
