SPC560P40L3CEFAR
RoHS
RoHS compliant
RoHS compliantPackage 100-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
32-bit Microcontrollers - MCU 32-BIT Embedded MCU 64 MHz, 5V 256kB
PDF
/
Buying Options
Total Price: USD $9.33
Unit Price: USD $9.328
≥1 USD $9.328
≥10 USD $8.57648
≥100 USD $8.221312
≥500 USD $7.24372
≥1000 USD $6.888218
≥3000 USD $6.4438
Inventory: 27
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 14mm
Technical
ROM (words) 262144
Address Bus Width 32
Number of Timers/Counters 10
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 16x10b
Bit Size 32
Supply Current-Max 65mA
Connectivity CANbus, LINbus, SPI, UART/USART
Program Memory Size 256KB 256K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals DMA, POR, PWM, WDT
Core Processor e200z0h
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
RAM Size 20K x 8
Number of I/O 64
Oscillator Type Internal
Memory Size 256kB
Interface CAN, LIN, SPI, UART, USART
Power Supplies 5V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 5V
Base Part Number SPC560P
Frequency 64MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
ECCN Code 3A991.A.2
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series Automotive, AEC-Q100, SPC56
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 100
Surface Mount YES
Package / Case 100-LQFP
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 26 Weeks
