C8051F971-A-GM
RoHS
/
Package QFN
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
SILICON LABS C8051F971-A-GM8 Bit Microcontroller, High Speed CIP-51, C8051F97x, 25 MHz, 32 KB, 8 KB, 32 Pins, QFN
PDF
/
Buying Options
Total Price: USD $5.3
Unit Price: USD $5.2976
≥1 USD $5.2976
≥10 USD $4.75992
≥100 USD $4.499572
≥500 USD $3.899606
≥1000 USD $3.699617
≥3000 USD $3.319668
Inventory: 1559
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Width 5mm
Length 5mm
Height 850μm
Technical
Number of SPI Channels 1
Number of I2C Channels 2
Number of PWM Channels 3
Number of ADC Channels 28
Core Architecture 8051
Number of Timers/Counters 4
Data Bus Width 8b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Frequency (Max) 25MHz
Peripherals CapSense, DMA, POR, PWM, WDT
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Memory Type FLASH
RAM Size 8kB
Number of I/O 30
Oscillator Type Internal
Memory Size 32kB
Min Supply Voltage 1.8V
Max Supply Voltage 3.6V
Interface I2C, SMBus, SPI, UART, USART
Operating Supply Voltage 3V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 25MHz
Supply Voltage 3V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Terminations 32
Part Status Active
Published 2014
Packaging Cut Tape
Physical
Weight 69.427982mg
Number of Pins 32
Package / Case QFN
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
