C8051F536-IT
RoHS
/
Package 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 2KB 12ADC 125C LIN 20Pin MCU
PDF
/
Buying Options
Total Price: USD $6.76
Unit Price: USD $6.75925
≥1 USD $6.75925
≥10 USD $5.5461
≥100 USD $5.37225
≥500 USD $5.19935
≥1000 USD $5.02645
Inventory: 1575
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Number of Pins 20
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2000
Series C8051F53x
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Matte Tin (Sn)
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 2.1V
Terminal Pitch 0.65mm
Frequency 25MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number C8051F53
Pin Count 20
Supply Voltage-Max (Vsup) 2.7V
Supply Voltage-Min (Vsup) 2V
Interface LIN, SPI, UART, USART
Memory Size 2kB
Oscillator Type Internal
Number of I/O 16
RAM Size 256 x 8
Voltage - Supply (Vcc/Vdd) 2V~5.25V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor 8051
Peripherals Brown-out Detect/Reset, POR, PWM, Temp Sensor, WDT
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 2KB 2K x 8
Connectivity LINbus, SPI, UART/USART
Bit Size 8
Data Converter A/D 16x12b
Access Time 25 μs
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 3
Dimensions
Height Seated (Max) 1.2mm
Length 6.5mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
