R5F111NJGLA#U0
RoHS
RoHS compliant
RoHS compliantPackage 85-VFLGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 256KB FLASH 85VFLGA
PDF
/
Inventory: 2871
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 12mm
Length 12mm
Technical
EEPROM Size 8K x 8
ROM (words) 262144
PWM Channels YES
DMA Channels NO
Has ADC YES
Data Converter A/D 11x8/12b; D/A 2x8b
Connectivity CSI, I2C, LINbus, UART/USART
Program Memory Size 256KB 256K x 8
Core Size 16-Bit
Program Memory Type FLASH
Peripherals LCD, LVD, POR, PWM, WDT
Core Processor RL78
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 1.6V~3.6V
RAM Size 16K x 8
Number of I/O 55
Oscillator Type Internal
Memory Size 256kB
Interface I2C, LIN, UART, USART
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 3.6V
Pin Count 85
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 24MHz
Terminal Pitch 0.5mm
Supply Voltage 3V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
Series RL78/L1C
Published 2014
Packaging Tray
Operating Temperature -40°C~105°C TA
Physical
Number of Pins 85
Surface Mount YES
Package / Case 85-VFLGA
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
