SPC5646BF0VLU1

NXP USA Inc.
RoHS
RoHS RoHS compliant
Package 176-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description MCU 32-Bit MPC56xx e200z4d RISC 3072KB Flash 3.3V/5V 176-Pin LQFP Tray
PDF
/
Inventory: 6539
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 12 Weeks

Physical

Mounting Type Surface Mount
Package / Case 176-LQFP
Surface Mount YES

Technical

Operating Temperature -40°C~105°C TA
Packaging Tray
Published 2007
Series MPC56xx Qorivva
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 176
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number SPC5646
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Oscillator Type Internal
Number of I/O 147
Speed 120MHz
RAM Size 192K x 8
Voltage - Supply (Vcc/Vdd) 3V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER RISC
Core Processor e200z4d
Peripherals DMA, POR, PWM, WDT
Clock Frequency 40MHz
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 3MB 3M x 8
Connectivity CANbus, I2C, LINbus, SCI, SPI
Bit Size 32
Data Converter A/D 27x10b, 5x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
EEPROM Size 64K x 8

Dimensions

Length 24mm
Width 24mm

Compliance

RoHS Status ROHS3 Compliant
