S912XDP512J1VALR
RoHS
RoHS compliant
RoHS compliantPackage 112-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 16-bit HCS12X CISC 512KB Flash 2.5V/5V 112-Pin LQFP T/R
PDF
/
Inventory: 2092
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Operating Temperature -40°C~105°C TA
Packaging Tape & Reel (TR)
Published 1996
Series HCS12X
JESD-609 Code e3
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 112
Terminal Finish Matte Tin (Sn)
Additional Feature ALSO REQUIRES 5V SUPPLY
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 2.5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
JESD-30 Code S-PQFP-G112
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 2.75V
Power Supplies 2.55V
Supply Voltage-Min (Vsup) 2.35V
Oscillator Type External
Number of I/O 91
Speed 80MHz
RAM Size 32K x 8
Voltage - Supply (Vcc/Vdd) 2.35V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Peripherals LVD, POR, PWM, WDT
Clock Frequency 16MHz
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 512KB 512K x 8
Connectivity CANbus, I2C, SCI, SPI
Supply Current-Max 110mA
Bit Size 16
Data Converter A/D 8x10b, 16x10b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
Address Bus Width 23
ROM (words) 524288
EEPROM Size 4K x 8
CPU Family CPU12
Screening Level AEC-Q100
External Data Bus Width 16
RAM (bytes) 32768
Physical
Surface Mount YES
Package / Case 112-LQFP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
Dimensions
Height Seated (Max) 1.6mm
Length 20mm
Width 20mm
Compliance
RoHS Status ROHS3 Compliant
