MC9S12C96VFUE
RoHS
RoHS compliant
RoHS compliantPackage 80-QFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
HCS12 HCS12 Microcontroller IC 16-Bit 25MHz 96KB (96K x 8) FLASH 80-QFP (14x14)
PDF
/
Inventory: 1531
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 80-QFP
Surface Mount YES
Technical
Operating Temperature -40°C~105°C TA
Packaging Tray
Published 2005
Series HCS12
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 80
Additional Feature ALSO REQUIRES 5V SUPPLY
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 2.5V
Terminal Pitch 0.65mm
Base Part Number MC9S12C96
JESD-30 Code S-PQFP-G80
Supply Voltage-Max (Vsup) 2.75V
Supply Voltage-Min (Vsup) 2.35V
Oscillator Type Internal
Number of I/O 60
Speed 25MHz
RAM Size 4K x 8
Voltage - Supply (Vcc/Vdd) 2.35V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Peripherals POR, PWM, WDT
Clock Frequency 50MHz
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 96KB 96K x 8
Connectivity CANbus, EBI/EMI, SCI, SPI
Bit Size 16
Data Converter A/D 8x10b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels NO
Address Bus Width 16
External Data Bus Width 16
Dimensions
Height Seated (Max) 2.45mm
Length 14mm
Width 14mm
Compliance
RoHS Status ROHS3 Compliant
