MC912D60CCPVE
RoHS
RoHS compliant
RoHS compliantPackage 112-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
CPU12 HC12 Microcontroller IC 16-Bit 8MHz 60KB (60K x 8) FLASH 112-LQFP (20x20)
PDF
/
Buying Options
Total Price: USD $40.27
Unit Price: USD $40.2724
≥1 USD $40.2724
≥10 USD $33.04385
≥100 USD $32.0112
≥500 USD $30.97855
≥1000 USD $29.9459
Inventory: 1385
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 112-LQFP
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Published 1994
Series HC12
JESD-609 Code e3
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 112
ECCN Code EAR99
Terminal Finish MATTE TIN
HTS Code 8542.31.00.01
Technology HCMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MC912D60
JESD-30 Code S-PQFP-G112
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Oscillator Type Internal
Number of I/O 68
Speed 8MHz
RAM Size 2K x 8
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor CPU12
Peripherals POR, PWM, WDT
Clock Frequency 16MHz
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 60KB 60K x 8
Connectivity CANbus, MI Bus, SCI, SPI
Bit Size 16
Data Converter A/D 16x8/10b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels NO
Address Bus Width 16
EEPROM Size 1K x 8
External Data Bus Width 16
Dimensions
Height Seated (Max) 1.6mm
Length 20mm
Width 20mm
Compliance
RoHS Status ROHS3 Compliant
