MC908AZ32ACFU
RoHS
/
Package 64-QFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
8-bit Microcontrollers - MCU 8BIT FLASH EEPROM/CAN
PDF
/
Buying Options
Total Price: USD $18.84
Unit Price: USD $18.84135
≥1 USD $18.84135
≥10 USD $15.45935
≥100 USD $14.97675
≥500 USD $14.4932
≥1000 USD $14.0106
Inventory: 1185
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 64-QFP
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Series HC08
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
HTS Code 8542.31.00.01
Technology HCMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.8mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MC908AZ32
JESD-30 Code S-PQFP-G64
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Supply Voltage-Min (Vsup) 4.5V
Oscillator Type Internal
Number of I/O 40
Speed 8MHz
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Peripherals LVD, POR, PWM
Clock Frequency 16MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 32KB 32K x 8
Connectivity CANbus, SCI, SPI
Bit Size 8
Data Converter A/D 15x8b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels NO
EEPROM Size 512 x 8
Dimensions
Height Seated (Max) 2.45mm
Length 14mm
Width 14mm
Compliance
RoHS Status Non-RoHS Compliant
