MC56F8167VPYE
RoHS
RoHS compliant
RoHS compliantPackage 160-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
Digital Signal Processors & Controllers - DSP, DSC 16 BIT HYBRID CONTROLLER
PDF
/
Buying Options
Total Price: USD $53.76
Unit Price: USD $53.758003
≥1 USD $53.758003
≥200 USD $20.804213
≥500 USD $20.072928
≥1000 USD $19.711881
Inventory: 1433
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 24mm
Length 24mm
Height Seated (Max) 1.6mm
Technical
Internal Bus Architecture MULTIPLE
Barrel Shifter YES
Format FIXED POINT
External Data Bus Width 16
Low Power Mode YES
Boundary Scan YES
ROM (words) 524288
Address Bus Width 24
Data Converter A/D 16x12b
Bit Size 16
Connectivity EBI/EMI, SCI, SPI
Program Memory Size 512KB 256K x 16
Core Size 16-Bit
Program Memory Type FLASH
Clock Frequency 120MHz
Peripherals POR, PWM, WDT
Core Processor 56800E
uPs/uCs/Peripheral ICs Type DIGITAL SIGNAL PROCESSOR, OTHER
Voltage - Supply (Vcc/Vdd) 2.25V~3.6V
RAM Size 16K x 16
Speed 40MHz
Number of I/O 76
Oscillator Type External
Supply Voltage-Min (Vsup) 2.25V
Power Supplies 2.53.3V
Supply Voltage-Max (Vsup) 2.75V
Qualification Status Not Qualified
JESD-30 Code S-PQFP-G160
Base Part Number MC56F8167
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Supply Voltage 2.5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
HTS Code 8542.31.00.01
Additional Feature ALSO REQUIRES 3.3V SUPPLY
Terminal Finish Matte Tin (Sn)
ECCN Code 3A991.A.2
Number of Terminations 160
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series 56F8xxx
Published 1998
Packaging Tray
Operating Temperature -40°C~105°C TA
Physical
Surface Mount YES
Package / Case 160-LQFP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
Alternative Model
