UPD78P078GF-3BA-A
RoHS
/
Package PQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
PDF
/
Inventory: 4242
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Package / Case PQFP
Number of Pins 100
Technical
Number of Terminations 100
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Technology MOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 2.2V
Frequency 5MHz
Pin Count 100
Temperature Grade INDUSTRIAL
Interface 2-Wire, UART
Max Supply Voltage 5.5V
Min Supply Voltage 1.8V
Memory Size 60kB
Number of I/O 88
RAM Size 2kB
Memory Type EPROM
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Bit Size 8
Frequency (Max) 5MHz
Has ADC YES
DMA Channels NO
Data Bus Width 8b
PWM Channels YES
DAC Channels YES
Number of Timers/Counters 5
Address Bus Width 16
Number of Programmable I/O 86
ROM Programmability OTPROM
Dimensions
Height Seated (Max) 3mm
Length 20mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
