PIC32MZ2048ECH144-I/PL
RoHS
RoHS compliant
RoHS compliantPackage 144-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
32 Bit MCU 2MB Flash 512KB RAM 200MHz 144Pin USB-HS ENET CAN SQI 2 Comp
PDF
/
Buying Options
Total Price: USD $15.63
Unit Price: USD $15.6288
≥1 USD $15.6288
≥10 USD $14.3264
≥100 USD $12.971288
Inventory: 103
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mounting Type Surface Mount
Package / Case 144-LQFP
Surface Mount YES
Number of Pins 144
Weight 1.290414g
Technical
Operating Temperature -40°C~85°C TA
Packaging Tray
Published 2016
Series PIC? 32MZ
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 144
ECCN Code 3A001.A.3
Terminal Finish Matte Tin (Sn) - annealed
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 200MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC32MZ2048EC
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Interface CAN, EBI/EMI, Ethernet, I2C, I2S, SPI, UART, USART, USB
Memory Size 2MB
Oscillator Type Internal
Number of I/O 120
RAM Size 512K x 8
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor MIPS32? microAptiv?
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 2MB 2M x 8
Connectivity CANbus, EBI/EMI, Ethernet, I2C, SPI, SQI, UART/USART, USB OTG
Bit Size 32
Data Converter A/D 48x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
Number of Timers/Counters 9
ROM (words) 524288
Core Architecture PIC
On Chip Program ROM Width 32
CPU Family PIC
Number of ADC Channels 48
Dimensions
Height Seated (Max) 1.6mm
Length 20mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
