PIC32MZ1025DAG176-I/2J
RoHS
RoHS compliant
RoHS compliantPackage 176-LQFP Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant GULL WING QUAD CMOS Microcontroller -40C~85C TA 64MHz 1.6mm 256K x 8
PDF
/
Buying Options
Total Price: USD $18.48
Unit Price: USD $18.48
≥1 USD $18.48
≥10 USD $16.9488
≥100 USD $15.338488
Inventory: 104
Minimum: 1
-
+
Technical Details
Technical
On Chip Program ROM Width 8
Screening Level TS 16949
External Data Bus Width 16
Address Bus Width 24
DAC Channels NO
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 45x12b
Bit Size 32
Connectivity CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, PMP, SPI, SQI, UART/USART, USB OTG
Program Memory Size 1MB 1M x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 64MHz
Peripherals Brown-out Detect/Reset, DMA, HLVD, I2S, POR, PWM, WDT
Core Processor MIPS32? microAptiv?
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 1.7V~3.6V
RAM Size 256K x 8
Speed 200MHz
Number of I/O 120
Oscillator Type Internal
Supply Voltage-Min (Vsup) 1.7V
Supply Voltage-Max (Vsup) 1.9V
JESD-30 Code S-PQFP-G176
Base Part Number PIC32MZ1025DA
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.4mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
HTS Code 8542.31.00.01
Number of Terminations 176
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series PIC? 32MZ DA
Published 2018
Packaging Tray
Operating Temperature -40°C~85°C TA
Dimensions
Height Seated (Max) 1.6mm
Length 20mm
Width 20mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Surface Mount YES
Package / Case 176-LQFP Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 4 Weeks
