PIC32MZ1024EFM124-I/TL
RoHS
RoHS compliant
RoHS compliantPackage 124-VFTLA Dual Rows, Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 1MB FLASH 124VTLA
PDF
/
Inventory: 7847
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Surface Mount
Package / Case 124-VFTLA Dual Rows, Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2015
Series PIC? 32MZ
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 124
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position BOTTOM
Terminal Form BUTT
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 200MHz
Base Part Number PIC32MZ1024EFM
JESD-30 Code S-XBCC-B124
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.1V
Interface CAN, EBI/EMI, Ethernet, I2C, SPI, UART, USART, USB
Memory Size 1MB
Oscillator Type Internal
Number of I/O 97
Speed 252 MHz
RAM Size 512K x 8
Voltage - Supply (Vcc/Vdd) 2.1V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor MIPS32? M-Class
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 1MB 1M x 8
Connectivity CANbus, EBI/EMI, Ethernet, I2C, PMP, SPI, SQI, UART/USART, USB OTG
Bit Size 32
Data Converter A/D 48x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
On Chip Program ROM Width 8
Screening Level TS 16949
Dimensions
Height Seated (Max) 0.9mm
Length 9mm
Width 9mm
Compliance
RoHS Status ROHS3 Compliant
