PIC32MZ1024EFK144T-I/PL
RoHS
RoHS compliant
RoHS compliantPackage 144-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 1MB FLASH 144LQFP
PDF
/
Inventory: 3968
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mounting Type Surface Mount
Package / Case 144-LQFP
Surface Mount YES
Number of Pins 144
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2015
Series PIC? 32MZ
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 144
Terminal Finish Matte Tin (Sn) - annealed
HTS Code 8542.31.00.01
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 200MHz
Base Part Number PIC32MZ1024EFK
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2.5/3.3V
Supply Voltage-Min (Vsup) 2.1V
Interface CAN, EBI/EMI, Ethernet, I2C, SPI, UART, USART, USB
Memory Size 1MB
Oscillator Type Internal
Number of I/O 120
RAM Size 256K x 8
Voltage - Supply (Vcc/Vdd) 2.1V~3.6V
Core Processor MIPS32? M-Class
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 1MB 1M x 8
Connectivity CANbus, EBI/EMI, Ethernet, I2C, PMP, SPI, SQI, UART/USART, USB OTG
Supply Current-Max 130mA
Bit Size 32
Data Converter A/D 48x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
On Chip Program ROM Width 32
CPU Family PIC
Dimensions
Length 20mm
Width 20mm
Compliance
RoHS Status ROHS3 Compliant
