PIC32MZ1024EFH144-I/PL
RoHS
RoHS compliant
RoHS compliantPackage 144-LQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant GULL WING QUAD CMOS Microcontroller -40C~85C TA 200MHz 1.6mm 512K x 8
PDF
/
Buying Options
Total Price: USD $13.57
Unit Price: USD $13.5696
≥1 USD $13.5696
≥10 USD $12.4344
≥100 USD $11.264088
Inventory: 97
Minimum: 1
-
+
Technical Details
Technical
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
On Chip Program ROM Width 8
Screening Level TS 16949
Data Converter A/D 48x12b
Bit Size 32
Connectivity CANbus, EBI/EMI, Ethernet, I2C, PMP, SPI, SQI, UART/USART, USB OTG
Program Memory Size 1MB 1M x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor MIPS32? M-Class
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 2.1V~3.6V
RAM Size 512K x 8
Speed 252 MHz
Number of I/O 120
Oscillator Type Internal
Memory Size 1MB
Interface CAN, EBI/EMI, Ethernet, I2C, SPI, UART, USART, USB
Supply Voltage-Min (Vsup) 2.1V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code S-PQFP-G144
Base Part Number PIC32MZ1024EFH
Frequency 200MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
HTS Code 8542.31.00.01
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 144
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series PIC? 32MZ
Published 2015
Packaging Tray
Operating Temperature -40°C~85°C TA
Dimensions
Height Seated (Max) 1.6mm
Length 20mm
Width 20mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Surface Mount YES
Package / Case 144-LQFP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
