PIC32MZ0512EFK064-E/MR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
512KB Flash, 128KB RAM, Crypto, CAN, 64 QFN 9x9x0.9mm TUBE
PDF
/
Inventory: 2654
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Surface Mount
Package / Case 64-VFQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Series Automotive, AEC-Q100, PIC? 32MZ
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Terminal Finish Matte Tin (Sn) - annealed
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Base Part Number PIC32MZ0512EFK
JESD-30 Code S-PQCC-N64
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.1V
Oscillator Type Internal
Number of I/O 46
Speed 180MHz
RAM Size 128K x 8
Voltage - Supply (Vcc/Vdd) 2.1V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor MIPS32? M-Class
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Clock Frequency 64MHz
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 512KB 512K x 8
Connectivity CANbus, Ethernet, I2C, PMP, SPI, SQI, UART/USART, USB OTG
Bit Size 32
Data Converter A/D 24x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
On Chip Program ROM Width 8
Screening Level AEC-Q100; TS 16949
Dimensions
Height Seated (Max) 0.9mm
Length 9mm
Width 9mm
Compliance
RoHS Status ROHS3 Compliant
