PIC32MX675F256LT-80I/BG
RoHS
RoHS compliant
RoHS compliantPackage 121-TFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 256KB FLASH 121BGA
PDF
/
Inventory: 4216
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 121-TFBGA
Number of Pins 121
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2010
Series PIC? 32MX
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 121
ECCN Code 3A001.A.3
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Subcategory Microcontrollers
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Supply Voltage 3.3V
Terminal Pitch 0.8mm
Frequency 80MHz
Base Part Number PIC32MX675F256L
Pin Count 121
Supply Voltage-Min (Vsup) 2.3V
Interface Ethernet, I2C, SPI, UART, USART, USB
Memory Size 256kB
Oscillator Type Internal
Number of I/O 83
RAM Size 64K x 8
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MIPS32? M4K?
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 256KB 256K x 8
Connectivity Ethernet, I2C, SPI, UART/USART, USB OTG
Supply Current-Max 98mA
Bit Size 32
Data Converter A/D 16x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 5
Core Architecture PIC
CPU Family PIC
Number of Programmable I/O 85
Number of UART Channels 6
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
