PIC32MX664F064L-I/BG
RoHS
RoHS compliant
RoHS compliantPackage 121-TFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 64KB FLASH 121TFBGA
PDF
/
Buying Options
Total Price: USD $56.67
Unit Price: USD $56.67225
≥1 USD $56.67225
≥10 USD $46.5006
≥100 USD $45.0471
≥500 USD $43.59455
≥1000 USD $42.14105
Inventory: 1249
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 10.0076mm
Length 9.9822mm
Height 838.2μm
Technical
Number of SPI Channels 4
Number of I2C Channels 5
Number of ADC Channels 16
Number of UART Channels 6
Number of Programmable I/O 85
Number of A/D Converters 1
Core Architecture PIC
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 16x10b
Bit Size 32
Connectivity Ethernet, I2C, SPI, UART/USART, USB OTG
Program Memory Size 64KB 64K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor MIPS32? M4K?
Number of Bits 32
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
RAM Size 32K x 8
Number of I/O 83
Oscillator Type Internal
Memory Size 64kB
Interface Ethernet, I2C, SPI, UART, USART, USB
Supply Voltage-Min (Vsup) 2.3V
Pin Count 121
Base Part Number PIC32MX664F064L
Frequency 80MHz
Terminal Pitch 0.8mm
Supply Voltage 3.3V
Terminal Form BALL
Terminal Position BOTTOM
Technology CMOS
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Number of Terminations 121
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e1
Series PIC? 32MX
Published 2010
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 121
Package / Case 121-TFBGA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 25 Weeks
