PIC32MX564F064HT-V/PT
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant GULL WING QUAD CMOS Microcontroller -40C~105C TA 80MHz 1.2mm 32K x 8
PDF
/
Inventory: 6252
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Length 10mm
Height Seated (Max) 1.2mm
Compliance
RoHS Status ROHS3 Compliant
Technical
Number of UART Channels 6
On Chip Program ROM Width 8
DAC Channels NO
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Data Converter A/D 16x10b
Bit Size 32
Connectivity CANbus, I2C, SPI, UART/USART, USB OTG
Program Memory Size 64KB 64K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor MIPS32? M4K?
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
RAM Size 32K x 8
Number of I/O 53
Oscillator Type Internal
Memory Size 64kB
Interface CAN, I2C, SPI, UART, USART, USB
Operating Supply Voltage 3.6V
Base Part Number PIC32MX564F064H
Frequency 80MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
HTS Code 8542.31.00.01
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series PIC? 32MX
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C TA
Physical
Surface Mount YES
Package / Case 64-TQFP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 24 Weeks
