PIC32MX534F064LT-I/PF
RoHS
RoHS compliant
RoHS compliantPackage 100-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 64KB FLASH 100TQFP
PDF
/
Inventory: 5919
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 12mm
Length 12mm
Height 1.05mm
Technical
Number of SPI Channels 4
Number of I2C Channels 5
Number of ADC Channels 16
Number of UART Channels 6
Number of A/D Converters 1
Core Architecture PIC
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 16x10b
Bit Size 32
Connectivity CANbus, I2C, SPI, UART/USART, USB OTG
Program Memory Size 64KB 64K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor MIPS32? M4K?
Number of Bits 32
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
RAM Size 16K x 8
Number of I/O 85
Oscillator Type Internal
Memory Size 64kB
Interface CAN, I2C, SPI, UART, USART, USB
Supply Voltage-Min (Vsup) 2.3V
Pin Count 100
Base Part Number PIC32MX534F064L
Frequency 80MHz
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series PIC? 32MX
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 100
Package / Case 100-TQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 24 Weeks
Alternative Model
