PIC32MX534F064H-V/MR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
32-bit Microcontrollers - MCU 64KB/16KB USB OTG 80 MHZ 10-B ADC DMA
PDF
/
Inventory: 6490
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 9mm
Height Seated (Max) 1mm
Technical
Number of UART Channels 6
On Chip Program ROM Width 8
Core Architecture PIC
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 16x10b
Bit Size 32
Connectivity CANbus, I2C, SPI, UART/USART, USB OTG
Program Memory Size 64KB 64K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor MIPS32? M4K?
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
RAM Size 16K x 8
Number of I/O 53
Oscillator Type Internal
Memory Size 64kB
Interface CAN, I2C, SPI, UART, USART, USB
Operating Supply Voltage 3.6V
Base Part Number PIC32MX534F064H
Frequency 80MHz
Supply Voltage 3.3V
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series PIC? 32MX
Published 2010
Packaging Tube
Operating Temperature -40°C~105°C TA
Physical
Surface Mount YES
Package / Case 64-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 24 Weeks
