PIC32MX530F128L-V/PT
RoHS
RoHS compliant
RoHS compliantPackage 100-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 32-Bit PIC32 PIC RISC 128KB Flash 2.5V/3.3V 100-Pin TQFP Tray
PDF
/
Buying Options
Total Price: USD $4.68
Unit Price: USD $4.67655
≥1 USD $4.67655
≥200 USD $1.810489
≥500 USD $1.746157
≥1000 USD $1.714647
Inventory: 1368
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 12mm
Height Seated (Max) 1.2mm
Technical
On Chip Program ROM Width 8
Core Architecture PIC
ROM (words) 131072
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 48x10b
Bit Size 32
Connectivity CANbus, I2C, IrDA, LINbus, PMP, SPI, UART/USART, USB OTG
Program Memory Size 128KB 128K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor MIPS32? M4K?
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
RAM Size 16K x 8
Number of I/O 81
Oscillator Type Internal
Memory Size 128kB
Interface CAN, Ethernet, I2C, I2S, IrDA, LIN, SPI, UART, USART, USB
Supply Voltage-Min (Vsup) 2.3V
Supply Voltage-Max (Vsup) 3.6V
Base Part Number PIC32MX530F128L
Frequency 40MHz
Terminal Pitch 0.4mm
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q100, PIC? 32MX
Published 2011
Packaging Tray
Operating Temperature -40°C~105°C TA
Physical
Number of Pins 100
Surface Mount YES
Package / Case 100-TQFP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
