PIC32MX470F512LT-120/PF
RoHS
RoHS compliant
RoHS compliantPackage 100-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
120MHz,2 analog comp.,2I2C,2SPI/I2S, 28 Ch. ADC,RTCC,DMA,PMP
PDF
/
Inventory: 9334
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 14mm
Length 14mm
Height Seated (Max) 1.2mm
Technical
Screening Level TS 16949
CPU Family PIC
On Chip Program ROM Width 8
ROM (words) 536576
DAC Channels NO
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 28x10b
Bit Size 32
Supply Current-Max 84mA
Connectivity I2C, IrDA, LINbus, PMP, SPI, UART/USART, USB OTG
Program Memory Size 512KB 512K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor MIPS32? M4K?
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
RAM Size 128K x 8
Number of I/O 81
Oscillator Type Internal
Memory Size 512kB
Interface I2C, IrDA, LIN, SPI, UART, USART, USB
Supply Voltage-Min (Vsup) 2.3V
Power Supplies 2.5/3.3V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status Not Qualified
JESD-30 Code S-PQFP-G100
Base Part Number PIC32MX470F512L
Frequency 120MHz
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Additional Feature ALSO AVAILABLE 2 DEDICATED DMA CHANNELS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series PIC? 32MX
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Surface Mount YES
Package / Case 100-TQFP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
Alternative Model
