PIC32MX450F256HT-I/MR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
32-bit Microcontrollers - MCU 100MHz 2anlg cmp 2I2C 2SPI/I2S 28Ch
PDF
/
Buying Options
Total Price: USD $6.18
Unit Price: USD $6.1776
≥1 USD $6.1776
Inventory: 1191
Minimum: 1
-
+
Technical Details
Technical
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 256KB 256K x 8
Connectivity I2C, IrDA, LINbus, PMP, SPI, UART/USART, USB OTG
Supply Current-Max 75mA
Bit Size 32
Data Converter A/D 28x10b
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
ROM (words) 274432
On Chip Program ROM Width 8
CPU Family PIC
Max Frequency 100MHz
Number of ADC Channels 28
Core Processor MIPS32? M4K?
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
RAM Size 64K x 8
Speed 80MHz
Number of I/O 49
Oscillator Type Internal
Memory Size 256kB
Interface I2C, SPI, UART
Power Supplies 2.5/3.3V
Operating Supply Voltage 3.6V
Qualification Status Not Qualified
JESD-30 Code S-PQCC-N64
Base Part Number PIC32MX450F256H
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Additional Feature ALSO AVAILABLE 2 DEDICATED DMA CHANNELS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series PIC? 32MX
Published 2015
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Dimensions
Height Seated (Max) 1mm
Length 9mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Surface Mount YES
Package / Case 64-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
