PIC32MX370F512LT-V/PF
RoHS
RoHS compliant
RoHS compliantPackage 100-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
32-bit Microcontrollers - MCU 80MHz 2anlg cmp 2I2C 2SPI/I2S 28 Ch
PDF
/
Inventory: 2661
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 100-TQFP
Surface Mount YES
Technical
Operating Temperature -40°C~105°C TA
Packaging Tape & Reel (TR)
Published 2015
Series PIC? 32MX
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Terminal Finish Matte Tin (Sn) - annealed
Additional Feature AEC-Q100 REVG (GRADE 2 -40 DEGC TO +105 DEGC) PLANNED
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Base Part Number PIC32MX370F512L
JESD-30 Code S-PQFP-G100
Qualification Status Not Qualified
Operating Supply Voltage 3.6V
Power Supplies 2.5/3.3V
Interface I2C, SPI, UART
Memory Size 512kB
Oscillator Type Internal
Number of I/O 85
RAM Size 128K x 8
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MIPS32? M4K?
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 512KB 512K x 8
Connectivity I2C, IrDA, LINbus, PMP, SPI, UART/USART
Supply Current-Max 60mA
Bit Size 32
Data Converter A/D 28x10b
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
ROM (words) 536576
On Chip Program ROM Width 8
CPU Family PIC
Max Frequency 80MHz
Screening Level TS 16949
Number of ADC Channels 28
Dimensions
Height Seated (Max) 1.2mm
Length 14mm
Compliance
RoHS Status ROHS3 Compliant
