PIC32MX330F064H-V/PT
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
32-bit Microcontrollers - MCU 80MHz 64KB 16 KBRAM CTMU I2S DMA USB-OTG
PDF
/
Buying Options
Total Price: USD $4.23
Unit Price: USD $4.230034
≥1 USD $4.230034
≥10 USD $3.990599
≥100 USD $3.764714
≥500 USD $3.55162
≥1000 USD $3.350578
Inventory: 1632
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 64-TQFP
Number of Pins 64
Technical
Operating Temperature -40°C~105°C TA
Packaging Tray
Published 2013
Series PIC? 32MX
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.6V
Frequency 80MHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number PIC32MX330F064H
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 2.3V
Supply Voltage-Min (Vsup) 3.3V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 64kB
Oscillator Type Internal
Number of I/O 53
RAM Size 16K x 8
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MIPS32? M4K?
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 64KB 64K x 8
Connectivity I2C, IrDA, LINbus, PMP, SPI, UART/USART
Supply Current-Max 60mA
Bit Size 32
Data Converter A/D 28x10b
Has ADC YES
DMA Channels NO
Data Bus Width 32b
PWM Channels YES
Number of Timers/Counters 5
Core Architecture PIC
CPU Family PIC
Screening Level AEC-Q100
Number of UART Channels 4
Dimensions
Length 10mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
