PIC32MX274F256BT-I/MM
RoHS
RoHS compliant
RoHS compliantPackage 28-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MIPS32? M4K? PIC? XLP? 32MX Microcontroller IC 32-Bit 72MHz 256KB (256K x 8) FLASH 28-QFN-S (6x6)
PDF
/
Buying Options
Total Price: USD $5.21
Unit Price: USD $5.2096
≥1 USD $5.2096
≥10 USD $4.7696
≥100 USD $4.3296
Inventory: 1159
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 6mm
Length 6mm
Height Seated (Max) 1mm
Technical
Screening Level TS 16949
On Chip Program ROM Width 8
DAC Channels NO
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 9x10b
Bit Size 32
Connectivity I2C, IrDA, LINbus, PMP, SPI, UART/USART, USB OTG
Program Memory Size 256KB 256K x 8
Core Size 32-Bit
Program Memory Type FLASH
Clock Frequency 50MHz
Peripherals Brown-out Detect/Reset, DMA, HLVD, I2S, POR, PWM, WDT
Core Processor MIPS32? M4K?
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.5V~3.6V
RAM Size 64K x 8
Speed 72MHz
Number of I/O 17
Oscillator Type Internal
Supply Voltage-Min (Vsup) 2.5V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code S-PQCC-N28
Base Part Number PIC32MX274F256B
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Series PIC? XLP? 32MX
Published 2018
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 28-VQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
