PIC32MX230F256DT-50I/PT
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 256KB FLASH 44TQFP
PDF
/
Inventory: 3328
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Surface Mount
Package / Case 44-TQFP
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2016
Series PIC? 32MX
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 44
Terminal Finish Matte Tin (Sn) - annealed
HTS Code 8542.31.00.01
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Supply Voltage 3.3V
Terminal Pitch 0.8mm
Frequency 50MHz
Base Part Number PIC32MX230F256D
JESD-30 Code S-PQFP-G44
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.3V
Interface I2C, IrDA, LIN, SPI, UART, USART, USB
Memory Size 256kB
Oscillator Type Internal
Number of I/O 33
RAM Size 16K x 8
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MIPS32? M4K?
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 256KB 256K x 8
Connectivity I2C, IrDA, LINbus, PMP, SPI, UART/USART, USB OTG
Bit Size 32
Data Converter A/D 13x10b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
ROM (words) 262144
On Chip Program ROM Width 8
Screening Level TS 16949
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Width 10mm
Compliance
RoHS Status ROHS3 Compliant
