PIC32MX230F064D-V/ML
RoHS
RoHS compliant
RoHS compliantPackage 44-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 64KB FLASH 44QFN
PDF
/
Inventory: 4528
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 8mm
Height Seated (Max) 1mm
Technical
Number of UART Channels 2
CPU Family PIC
Core Architecture PIC
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 13x10b
Bit Size 32
Supply Current-Max 30mA
Connectivity I2C, IrDA, LINbus, PMP, SPI, UART/USART, USB OTG
Program Memory Size 64KB 64K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor MIPS32? M4K?
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
RAM Size 16K x 8
Number of I/O 33
Oscillator Type Internal
Memory Size 64kB
Interface I2C, I2S, IrDA, LIN, SPI, UART, USART, USB
Supply Voltage-Max (Vsup) 3.6V
Pin Count 44
Base Part Number PIC32MX230F064D
Time@Peak Reflow Temperature-Max (s) 40
Frequency 40MHz
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 44
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q100, PIC? 32MX
Published 2012
Packaging Tube
Operating Temperature -40°C~105°C TA
Physical
Number of Pins 44
Package / Case 44-VQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
