PIC32MX230F064D-I/PT
RoHS
RoHS compliant
RoHS compliantPackage 44-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 64KB FLASH 44TQFP
PDF
/
Buying Options
Total Price: USD $3.66
Unit Price: USD $3.6608
≥1 USD $3.6608
≥10 USD $3.3528
≥100 USD $3.036
Inventory: 350
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 10mm
Technical
Number of UART Channels 2
Number of Programmable I/O 34
CPU Family PIC
Core Architecture PIC
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 13x10b
Bit Size 32
Supply Current-Max 30mA
Connectivity I2C, IrDA, LINbus, PMP, SPI, UART/USART, USB OTG
Program Memory Size 64KB 64K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor MIPS32? M4K?
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
RAM Size 16K x 8
Number of I/O 33
Oscillator Type Internal
Memory Size 64kB
Interface I2C, I2S, IrDA, LIN, SPI, UART, USART, USB
Supply Voltage-Max (Vsup) 3.6V
Pin Count 44
Base Part Number PIC32MX230F064D
Time@Peak Reflow Temperature-Max (s) 40
Frequency 40MHz
Terminal Pitch 0.8mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 44
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? 32MX
Published 2009
Packaging Tray
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 44
Surface Mount YES
Package / Case 44-TQFP
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
