PIC32MX210F016BT-I/SS
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 16KB FLASH 28SSOP
PDF
/
Inventory: 2989
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Frequency 40MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC32MX210F016B
Pin Count 28
Operating Supply Voltage 3.6V
Interface I2C, I2S, IrDA, LIN, SPI, UART, USART, USB
Memory Size 16kB
Oscillator Type Internal
Number of I/O 19
RAM Size 4K x 8
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MIPS32? M4K?
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? 32MX
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Number of UART Channels 2
CPU Family PIC
Core Architecture PIC
ROM (words) 16384
Number of Timers/Counters 15
DAC Channels NO
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 9x10b
Bit Size 32
Supply Current-Max 30mA
Connectivity I2C, IrDA, LINbus, PMP, SPI, UART/USART, USB OTG
Program Memory Size 16KB 16K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Physical
Number of Pins 28
Surface Mount YES
Package / Case 28-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
