PIC32MX210F016B-V/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 16KB FLASH 28SOIC
PDF
/
Inventory: 3028
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 28
Technical
Operating Temperature -40°C~105°C TA
Packaging Tube
Published 2012
Series Automotive, AEC-Q100, PIC? 32MX
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Frequency 40MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC32MX210F016B
Pin Count 28
Operating Supply Voltage 3.6V
Interface I2C, I2S, IrDA, LIN, SPI, UART, USART, USB
Memory Size 16kB
Oscillator Type Internal
Number of I/O 19
RAM Size 4K x 8
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MIPS32? M4K?
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 16KB 16K x 8
Connectivity I2C, IrDA, LINbus, PMP, SPI, UART/USART, USB OTG
Supply Current-Max 30mA
Bit Size 32
Data Converter A/D 9x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 32b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 15
ROM (words) 16384
Core Architecture PIC
CPU Family PIC
Number of UART Channels 2
Dimensions
Length 17.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
