PIC32MX170F256D-50I/ML
RoHS
RoHS compliant
RoHS compliantPackage 44-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
32-bit Microcontrollers - MCU 256KB Flash 64KB RAM 50MHz, 10-bit ADC
PDF
/
Buying Options
Total Price: USD $5.02
Unit Price: USD $5.016
≥1 USD $5.016
≥10 USD $4.5936
≥100 USD $4.1712
Inventory: 371
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 44-VQFN Exposed Pad
Weight 369.989626mg
Number of Pins 44
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 8mm
Length 8mm
Height 950μm
Technical
Number of I2C Channels 2
Number of ADC Channels 13
Number of Programmable I/O 34
Screening Level TS 16949
Core Architecture PIC
Number of Timers/Counters 5
PWM Channels YES
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 13x10b
Bit Size 32
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 256KB 256K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor MIPS32? M4K?
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
RAM Size 64K x 8
Number of I/O 35
Oscillator Type Internal
Memory Size 256kB
Interface I2C, I2S, IrDA, LIN, SPI, UART, USART, USB
Supply Voltage-Max (Vsup) 3.6V
Base Part Number PIC32MX170F256D
Time@Peak Reflow Temperature-Max (s) 40
Frequency 50MHz
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 44
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? 32MX
Published 2005
Packaging Tube
Operating Temperature -40°C~85°C TA
