PIC32MX150F128B-I/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 128KB FLASH 28SOIC
PDF
/
Buying Options
Total Price: USD $7.69
Unit Price: USD $7.68701
≥1 USD $7.68701
≥10 USD $7.251896
≥100 USD $6.84141
≥500 USD $6.454155
≥1000 USD $6.088829
Inventory: 1309
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 7.5mm
Length 17.9mm
Height 2.35mm
Technical
Number of I2C Channels 2
Number of PWM Channels 1
Number of ADC Channels 10
CPU Family PIC
Core Architecture PIC
Number of Timers/Counters 5
Data Bus Width 32b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 10x10b
Bit Size 32
Supply Current-Max 30mA
Connectivity I2C, IrDA, LINbus, PMP, SPI, UART/USART
Program Memory Size 128KB 128K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor MIPS32? M4K?
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
RAM Size 32K x 8
Number of I/O 21
Oscillator Type Internal
Memory Size 128kB
Interface I2C, I2S, IrDA, LIN, SPI, UART, USART
Supply Voltage-Max (Vsup) 3.6V
Pin Count 28
Base Part Number PIC32MX150F128B
Time@Peak Reflow Temperature-Max (s) 40
Frequency 40MHz
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? 32MX
Published 2010
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 28
Surface Mount YES
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
