PIC32MX130F256B-V/SP
RoHS
RoHS compliant
RoHS compliantPackage 28-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 256KB FLASH 28SDIP
PDF
/
Inventory: 3171
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mounting Type Through Hole
Package / Case 28-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature -40°C~105°C TA
Packaging Tube
Published 2016
Series Automotive, AEC-Q100, PIC? 32MX
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 28
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Supply Voltage 3.3V
Terminal Pitch 2.54mm
Frequency 40MHz
Base Part Number PIC32MX130F256B
JESD-30 Code R-PDIP-T28
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2.5/3.3V
Supply Voltage-Min (Vsup) 2.3V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 256kB
Oscillator Type Internal
Number of I/O 21
RAM Size 16K x 8
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor MIPS32? M4K?
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 256KB 256K x 8
Connectivity I2C, IrDA, LINbus, PMP, SPI, UART/USART
Supply Current-Max 30mA
Bit Size 32
Data Converter A/D 10x10b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels NO
On Chip Program ROM Width 8
CPU Family PIC
Screening Level TS 16949
Dimensions
Height Seated (Max) 5.08mm
Length 34.671mm
Width 7.62mm
Compliance
RoHS Status ROHS3 Compliant
