PIC32MX120F032BT-50I/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 32KB FLASH 28SOIC
PDF
/
Inventory: 5823
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Length 17.9mm
Technical
Number of UART Channels 2
Screening Level TS 16949
CPU Family PIC
On Chip Program ROM Width 8
DAC Channels NO
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 10x10b
Bit Size 32
Supply Current-Max 30mA
Connectivity I2C, IrDA, LINbus, PMP, SPI, UART/USART
Program Memory Size 32KB 32K x 8
Core Size 32-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Core Processor MIPS32? M4K?
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2.3V~3.6V
RAM Size 8K x 8
Number of I/O 21
Oscillator Type Internal
Interface I2C, IrDA, LIN, SPI, UART, USART
Supply Voltage-Max (Vsup) 3.6V
Qualification Status Not Qualified
Base Part Number PIC32MX120F032B
Time@Peak Reflow Temperature-Max (s) 40
Frequency 50MHz
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? 32MX
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
