PIC24HJ64GP502-E/SO
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 64KB FLASH 28SOIC
PDF
/
Inventory: 4969
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Number of Pins 28
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Published 2009
Series Automotive, AEC-Q100, PIC? 24H
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code 3A991.A.2
Terminal Finish Matte Tin (Sn)
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Frequency 40MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC24HJ64GP502
Pin Count 28
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Interface CAN, I2C, IrDA, LIN, SPI, UART, USART
Memory Size 64kB
Oscillator Type Internal
Number of I/O 21
RAM Size 8K x 8
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 64KB 22K x 24
Connectivity CANbus, I2C, IrDA, LINbus, PMP, SPI, UART/USART
Supply Current-Max 76mA
Bit Size 16
Data Converter A/D 10x10b/12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 5
CPU Family PIC
Dimensions
Length 17.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
