PIC24HJ256GP206T-I/PT
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 256KB FLASH 64TQFP
PDF
/
Buying Options
Total Price: USD $7.13
Unit Price: USD $7.128
≥1 USD $7.128
≥10 USD $6.5208
≥100 USD $6.281
Inventory: 1267
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 64-TQFP
Number of Pins 64
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2005
Series PIC? 24H
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Subcategory Microcontrollers
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Frequency 40MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC24HJ256GP206
Pin Count 64
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 256kB
Oscillator Type Internal
Number of I/O 53
Speed 32 MHz
RAM Size 16K x 8
Voltage - Supply (Vcc/Vdd) 3V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 256KB 85.5K x 24
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Bit Size 16
Data Converter A/D 18x10b, 18x12b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 9
ROM (words) 262144
CPU Family PIC
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
