PIC24HJ128GP306T-I/PT
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
16-bit Microcontrollers - MCU 40MIPS 128KB
PDF
/
Inventory: 6962
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
DAC Channels NO
Number of Timers/Counters 13
CPU Family PIC
Max Frequency 40MHz
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 18x10b/12b
Bit Size 16
Supply Current-Max 90mA
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 128KB 43K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, DMA, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 3V~3.6V
RAM Size 16K x 8
Speed 40 MIPs
Number of I/O 53
Oscillator Type Internal
Memory Size 128kB
Interface CAN, I2C, IrDA, LIN, SPI, UART, USART
Supply Voltage-Min (Vsup) 3V
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 3.6V
Pin Count 64
Base Part Number PIC24HJ128GP306
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish Matte Tin (Sn)
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series PIC? 24H
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Dimensions
Height Seated (Max) 1.2mm
Length 10mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 64
Surface Mount YES
Package / Case 64-TQFP
Mounting Type Surface Mount
