PIC24FV08KM102-E/SS
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 16-bit PIC24F PIC RISC 8KB Flash 2.5V/3.3V/5V 28-Pin SSOP Tube
PDF
/
Inventory: 9199
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 10.2mm
Height Seated (Max) 2mm
Technical
On Chip Data RAM Width 16
Number of External Interrupts 3
Number of Serial I/Os 1
RAM (words) 512
Integrated Cache NO
Format FIXED-POINT
Low Power Mode NO
On Chip Program ROM Width 24
EEPROM Size 512 x 8
Number of Timers/Counters 3
DAC Channels NO
PWM Channels YES
DMA Channels NO
Has ADC YES
Data Converter A/D 19x10b/12b
Bit Size 16
Supply Current-Max 10mA
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 8KB 2.75K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, LVD, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Voltage - Supply (Vcc/Vdd) 2V~5V
RAM Size 1K x 8
Number of I/O 23
Oscillator Type Internal
Memory Size 8kB
Interface I2C, SPI, UART
Supply Voltage-Min (Vsup) 2V
Power Supplies 2.5/5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
Base Part Number PIC24FV08KM102
Frequency 32MHz
Terminal Pitch 0.65mm
Supply Voltage 5V
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Microcontrollers
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PIC? XLP? 24F
Published 2013
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 28
Package / Case 28-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
