PIC24FJ64GB204T-I/ML
RoHS
RoHS compliant
RoHS compliantPackage 44-VQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 16-bit PIC24F PIC RISC 64KB Flash 3.3V 44-Pin QFN EP T/R
PDF
/
Inventory: 3731
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 8mm
Length 8mm
Height Seated (Max) 1mm
Technical
Number of DMA Channels 6
On Chip Data RAM Width 16
RAM (words) 4096
On Chip Program ROM Width 24
ROM (words) 22016
Number of Timers/Counters 5
DAC Channels YES
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 12x10b/12b
Bit Size 16
Supply Current-Max 7.6mA
Connectivity I2C, IrDA, LINbus, PMP/PSP, SmartCard, SPI, UART/USART
Program Memory Size 64KB 64K x 8
Core Size 16-Bit
Program Memory Type FLASH
Peripherals AES, Brown-out Detect/Reset, DMA, I2S, HLVD, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 2V~3.6V
RAM Size 8K x 8
Number of I/O 34
Oscillator Type Internal
Memory Size 64kB
Interface I2C, SPI, UART
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Base Part Number PIC24FJ64GB204
Time@Peak Reflow Temperature-Max (s) 40
Frequency 32MHz
Supply Voltage 3V
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
Terminal Finish Matte Tin (Sn)
Number of Terminations 44
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 24F
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 44
Package / Case 44-VQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
