PIC24FJ256GB406-I/MR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
MCU 16-Bit PIC24 PIC RISC 256KB Flash 2.5V/3.3V 64-Pin QFN EP Tube
PDF
/
Buying Options
Total Price: USD $5.99
Unit Price: USD $5.9928
≥1 USD $5.9928
≥10 USD $5.4824
≥100 USD $4.9808
Inventory: 133
Minimum: 1
-
+
Technical Details
Physical
Surface Mount YES
Number of Pins 64
Package / Case 64-VFQFN Exposed Pad
Mounting Type Surface Mount
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2005
Series PIC? XLP? 24F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 64
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Terminal Position QUAD
Terminal Form NO LEAD
Supply Voltage 3.3V
Frequency 32MHz
Base Part Number PIC24FJ256GB406
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2V
Interface I2C, IrDA, LIN, SPI, UART, USART, USB
Memory Size 256kB
Oscillator Type Internal
Number of I/O 52
RAM Size 16K x 8
Voltage - Supply (Vcc/Vdd) 2V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, DMA, LCD, LVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 256KB 85.5K x 24
Connectivity I2C, IrDA, LINbus, PMP/PSP, SPI, UART/USART, USB OTG
Supply Current-Max 9mA
Bit Size 16
Data Converter A/D 16x10b/12b; D/A 1x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels YES
Data Bus Width 16b
PWM Channels YES
DAC Channels YES
Number of Timers/Counters 5
ROM (words) 87381
On Chip Program ROM Width 24
CPU Family PIC
Boundary Scan YES
Low Power Mode YES
Format FIXED-POINT
Integrated Cache NO
RAM (words) 8192
Number of External Interrupts 5
On Chip Data RAM Width 16
Number of DMA Channels 6
Supply Chain
Factory Lead Time 11 Weeks
Dimensions
Height Seated (Max) 1mm
Length 9mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
