PIC24FJ256DA106T-I/PT
RoHS
RoHS compliant
RoHS compliantPackage 64-TQFP
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant GULL WING QUAD CMOS Microcontroller -40C~85C TA 18mA 32MHz 1.2mm
PDF
/
Inventory: 6633
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 10mm
Height Seated (Max) 1.2mm
Technical
CPU Family PIC
ROM (words) 262144
Number of Timers/Counters 5
DAC Channels NO
PWM Channels YES
Data Bus Width 16b
DMA Channels YES
Has ADC YES
Watchdog Timer Yes
Data Converter A/D 16x10b
Bit Size 16
Supply Current-Max 18mA
Connectivity I2C, IrDA, SPI, UART/USART, USB OTG
Program Memory Size 256KB 85.5K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, GFX, LVD, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 2.2V~3.6V
RAM Size 24K x 8
Number of I/O 52
Oscillator Type Internal
Memory Size 256kB
Interface I2C, IrDA, SPI, UART, USART, USB
Supply Voltage-Min (Vsup) 2.2V
Supply Voltage-Max (Vsup) 3.6V
Pin Count 64
Base Part Number PIC24FJ256DA106
Frequency 32MHz
Supply Voltage 3.3V
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
Subcategory Microcontrollers
Terminal Finish MATTE TIN
ECCN Code 3A991.A.2
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e3
Series PIC? 24F
Published 2006
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 64
Package / Case 64-TQFP
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 25 Weeks
