PIC24FJ1024GB606-E/MR
RoHS
RoHS compliant
RoHS compliantPackage 64-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
ROHS3Compliant NO LEAD QUAD CMOS Microcontroller -40C~125C TA 32MHz 0.9mm 32K x 8
PDF
/
Inventory: 2637
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 9mm
Length 9mm
Height Seated (Max) 0.9mm
Technical
RAM (bytes) 32768
External Data Bus Width 8
Screening Level ISO/TS-16949
On Chip Program ROM Width 8
ROM (words) 1048576
Address Bus Width 16
DAC Channels NO
PWM Channels YES
DMA Channels YES
Has ADC YES
Data Converter A/D 16x12b SAR
Bit Size 16
Connectivity I2C, IrDA, LINbus, PMP, SPI, UART/USART, USB OTG
Program Memory Size 1MB 341.5K x 24
Core Size 16-Bit
Program Memory Type FLASH
Clock Frequency 32MHz
Peripherals Brown-out Detect/Reset, DMA, HLVD, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 2V~3.6V
RAM Size 32K x 8
Speed 32MHz
Number of I/O 53
Oscillator Type Internal
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 3.6V
JESD-30 Code S-PQCC-N64
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Terminal Form NO LEAD
Terminal Position QUAD
Technology CMOS
HTS Code 8542.31.00.01
Additional Feature ITS ALSO AVAILABLE WITH 16-CH 10-BIT
Number of Terminations 64
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series Automotive, AEC-Q100, PIC? 24F
Operating Temperature -40°C~125°C TA
Physical
Surface Mount YES
Package / Case 64-VFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
