PIC24F16KL402T-I/SS
RoHS
RoHS compliant
RoHS compliantPackage 28-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 16BIT 16KB FLASH 28SSOP
PDF
/
Inventory: 5304
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 28-SSOP (0.209, 5.30mm Width)
Surface Mount YES
Number of Pins 28
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2011
Series PIC? XLP? 24F
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
ECCN Code 3A991.A.2
Terminal Finish Matte Tin (Sn) - annealed
Additional Feature ALSO OPERATES 1.8V AT 8MHZ
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Frequency 32MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number PIC24F16KL402
Pin Count 28
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2/3.3V
Supply Voltage-Min (Vsup) 3V
Interface I2C, IrDA, LIN, SPI, UART, USART
Memory Size 16kB
Oscillator Type Internal
Number of I/O 24
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Core Processor PIC
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Program Memory Type FLASH
Core Size 16-Bit
Program Memory Size 16KB 5.5K x 24
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Supply Current-Max 12mA
Bit Size 16
Data Converter A/D 12x10b
Watchdog Timer Yes
Has ADC YES
DMA Channels NO
Data Bus Width 16b
PWM Channels YES
DAC Channels NO
Number of Timers/Counters 4
EEPROM Size 512 x 8
On Chip Program ROM Width 24
CPU Family PIC
Dimensions
Height Seated (Max) 2mm
Length 10.2mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
