PIC24F16KA304-E/MV

Microchip Technology
RoHS
RoHS RoHS compliant
Package 48-UFQFN Exposed Pad
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description IC MCU 16BIT 16KB FLASH 48UQFN
PDF
/
Inventory: 9603
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Technical

Number of Programmable I/O 38
Max Frequency 8MHz
EEPROM Size 512 x 8
Core Architecture PIC
Number of Timers/Counters 5
Data Bus Width 16b
Watchdog Timer Yes
Data Converter A/D 16x12b
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 16KB 5.5K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Core Processor PIC
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
Memory Type FLASH
RAM Size 2K x 8
Speed 32MHz
Number of I/O 39
Oscillator Type Internal
Memory Size 16kB
Min Supply Voltage 1.8V
Max Supply Voltage 3.6V
Interface I2C, IrDA, LIN, SPI, UART, USART
Base Part Number PIC24F16KA304
Frequency 32MHz
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series PIC? XLP? 24F
Published 2006
Packaging Tube
Operating Temperature -40°C~125°C TA

Physical

Supplier Device Package 48-UQFN (6x6)
Number of Pins 48
Package / Case 48-UFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
