PIC24F04KL101-E/SS
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
16-bit Microcontrollers - MCU PIC24F Core 4KB Flsh 512B RAM 3V
PDF
/
Inventory: 9801
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 20-SSOP (0.209, 5.30mm Width)
Number of Pins 20
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Number of Programmable I/O 18
Max Frequency 32MHz
ROM (words) 1024
Number of Timers/Counters 3
Data Bus Width 16b
Watchdog Timer Yes
Connectivity I2C, IrDA, LINbus, SPI, UART/USART
Program Memory Size 4KB 1.375K x 24
Core Size 16-Bit
Program Memory Type FLASH
Peripherals Brown-out Detect/Reset, HLVD, POR, PWM, WDT
Core Processor PIC
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
RAM Size 512 x 8
Number of I/O 17
Oscillator Type Internal
Memory Size 4kB
Interface I2C, SPI, UART
Operating Supply Voltage 3.6V
Base Part Number PIC24F04KL101
Time@Peak Reflow Temperature-Max (s) 40
Peak Reflow Temperature (Cel) 260
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PIC? XLP? 24F
Published 2011
Packaging Tube
Operating Temperature -40°C~125°C TA
